Create an RPA Flow that Connects to Google Cloud Storage Data in UiPath Studio

UiPath is a Robotic Process Automation (RPA) platform with rich features and an easy-to-use UI that enables non-developers to create process automation. By using UiPath Studio, you can build an RPA program just like drawing a diagram. With the CData ODBC Driver for Google Cloud Storage, users can embed Google Cloud Storage data in the workflow.

This article walks through using the Google Cloud Storage ODBC Driver in UiPath Studio to create an RPA program that accesses Google Cloud Storage data.

Configure the Connection to Google Cloud Storage

If you have not already, first specify connection properties in an ODBC DSN (data source name). This is the last step of the driver installation. You can use the Microsoft ODBC Data Source Administrator to create and configure ODBC DSNs.

Authenticate with a User Account

You can connect without setting any connection properties for your user credentials. After setting InitiateOAuth to GETANDREFRESH, you are ready to connect.

When you connect, the Google Cloud Storage OAuth endpoint opens in your default browser. Log in and grant permissions, then the OAuth process completes

Authenticate with a Service Account

Service accounts have silent authentication, without user authentication in the browser. You can also use a service account to delegate enterprise-wide access scopes.

You need to create an OAuth application in this flow. See the Help documentation for more information. After setting the following connection properties, you are ready to connect:

• InitiateOAuth: Set this to GETANDREFRESH.
• OAuthJWTCertType: Set this to "PFXFILE".
• OAuthJWTCert: Set this to the path to the .p12 file you generated.
• OAuthJWTCertPassword: Set this to the password of the .p12 file.
• OAuthJWTCertSubject: Set this to "*" to pick the first certificate in the certificate store.
• OAuthJWTIssuer: In the service accounts section, click Manage Service Accounts and set this field to the email address displayed in the service account Id field.
• OAuthJWTSubject: Set this to your enterprise Id if your subject type is set to "enterprise" or your app user Id if your subject type is set to "user".
• ProjectId: Set this to the Id of the project you want to connect to.

The OAuth flow for a service account then completes.

Connect UiPath Studio to Google Cloud Storage Data

Now you are ready to use Google Cloud Storage data ODBC DSN in UiPath Studio with the following steps.

1. From the Start page, click Blank to create a New Project.
2. Click Manage Packages then search for and install UiPath.Database.Activities.
3. Navigate to the Activities and drop a Flowchart (Workflow -> Flowchart -> Flowchart) onto the process.
4. Drop a database Connect activity (App Integration -> Datbase -> Connect) after the Start activity.
5. Double-click the Connect activity and configure the Connection.
   1. Click the Connection Wizard
   2. Select "Microsoft ODBC Data Source"
   3. In Connection Properties, select your DSN (CData GoogleCloudStorage Source) and click OK
6. To store Connection info, create a variable and bind to Output in the Properties section. Choose DatabaseConnection in Output.


Create an Execute Query Activity

With the connection configured, we are ready to query Google Cloud Storage data in our RPA.

1. From the Activities navigation, select Execute Query and drop it on the Flowchart.
2. Double-click the Execute Query activity and set the properties as follows:
   • ExistingDbConnection: Your Connection variable
   • Sql: SELECT statement like SELECT Name, OwnerId FROM Buckets WHERE Name = 'TestBucket'
   • DataTable: Create and use a variable with the Type System.Data.DataTable

Create Write CSV Activity

With the Connection and Execute Query activities configured, we are ready to add a Write CSV activity to the Flowchart to replicate the Google Cloud Storage data.

1. From the Activities navigation, select Write CSV and drop it after the Execute Query activity.
2. Double-click the Write CSV activity and set the properties as follows:
   • FilePath: Set to a file (new or existing) on disk (i.e.: C:\UiPath[id]-data.csv
   • DataTable: Set to the DataTable variable you created earlier

Connect the Activities and Run the Flowchart

If they are not already connected, connect each Activity that you created to complete the RPA project for extracting Google Cloud Storage data and exporting it to CSV.

Click Run to extract Google Cloud Storage data and create a CSV file.

In this article, we used the CData ODBC Driver for Google Cloud Storage to create an automation flow that accesses Google Cloud Storage data in UiPath Studio. Download a free, 30-day trial of the ODBC Driver and start working with live Google Cloud Storage data in UiPath Studio today!
