Design BIRT Reports on SharePoint Data

The CData JDBC Driver for SharePoint integrates connectivity to SharePoint APIs into your data-driven Java applications. You can use the CData JDBC Driver for SharePoint with the BIRT (Business Intelligence Reporting Tools) platform to create BIRT reports that reflect changes to your data in real time.

1. If you have not already done so, install the BIRT Framework plugin and the Database Development plugin for Eclipse.
2. Click File -> New -> Report. The Report Design perspective is opened.
3. In the Data Explorer, right-click Data Sources and click New Data Source.
4. Select the Create from a Data Source Type in the Following List option and select JDBC Data Source.
5. Click Manage Drivers and add the driver JAR, located in the lib subfolder of the installation folder.
6. In the Database URL box, enter the JDBC URL containing the connection string.

   Set the URL property to the base SharePoint site or to a sub-site. This allows you to query any lists and other SharePoint entities defined for the site or sub-site.

   The User and Password properties, under the Authentication section, must be set to valid SharePoint user credentials when using SharePoint On-Premise.

   If you are connecting to SharePoint Online, set the SharePointEdition to SHAREPOINTONLINE along with the User and Password connection string properties. For more details on connecting to SharePoint Online, see the "Getting Started" chapter of the help documentation

   Built-in Connection String Designer

   For assistance in constructing the JDBC URL, use the connection string designer built into the SharePoint JDBC Driver. Either double-click the JAR file or execute the jar file from the command-line.

   java -jar cdata.jdbc.sharepoint.jar

   Fill in the connection properties and copy the connection string to the clipboard.

   When you configure the JDBC URL, you may also want to set the Max Rows connection property. This will limit the number of rows returned, which is especially helpful for improving performance when designing reports and visualizations.

   A typical JDBC URL is below:

   jdbc:sharepoint:User=myuseraccount;Password=mypassword;Auth Scheme=NTLM;URL=http://sharepointserver/mysite;SharePointEdition=SharePointOnPremise;
7. Right-click the Data Sets folder and select the JDBC data source for SharePoint.
8. In the resulting dialog, build the SELECT query to be used to retrieve the data for the report. This article uses the following query: SELECT Name, Revenue FROM MyCustomList
9. In the Palette, drag a Chart onto the editor. The chart wizard is displayed.
10. After selecting the chart type, drag columns onto the chart fields on the Select Data tab.
11. Click Run -> View Report -> In Web Viewer to view the report.

Your BIRT reports can now pick up any updates to SharePoint data.

To publish the report to your application server, add the driver JAR to the BIRT Viewer's classpath. For more information, see the CData KB for guides to deploying the JDBC Driver on Java application servers.
