Enable the SQL Analysis Services JDBC Driver in KNIME

Use standard data access components in KNIME to create charts and reports with SQL Analysis Services data.

One of the strengths of the CData JDBC Driver for SQL Analysis Services is its cross-platform support, enabling integration with major BI tools. Follow the procedure below to access SQL Analysis Services data in KNIME and to create a chart from SQL Analysis Services data using the report designer.

Define a New JDBC Connection to SQL Analysis Services Data

  1. Install the Report Designer extension: Click File -> Install KNIME Extensions, and filter on "Report".
  2. In a new workflow, click File -> Preferences and expand the KNIME -> Databases node to add cdata.jdbc.ssas.jar. The driver JAR is located in the lib subfolder of the installation directory.
  3. In the Node Repository view, expand the Database -> Read/Write node and drag a Database Reader onto the workflow editor.
  4. Double-click the Database Reader and set the following properties:

    • Database Driver: In the menu, select the driver name, cdata.jdbc.ssas.SSASDriver
    • Database URL: Enter the connection properties. The JDBC URL begins with jdbc:ssas: and is followed by a semicolon-separated list of connection properties.

      To connect, provide authentication and set the Url property to a valid SQL Server Analysis Services endpoint. You can connect to SQL Server Analysis Services instances hosted over HTTP with XMLA access. See the Microsoft documentation to configure HTTP access to SQL Server Analysis Services.

      To secure connections and authenticate, set the corresponding connection properties, below. The data provider supports the major authentication schemes, including HTTP and Windows, as well as SSL/TLS.

      • HTTP Authentication

        Set AuthScheme to "Basic" or "Digest" and set User and Password. Specify other authentication values in CustomHeaders.

      • Windows (NTLM)

        Set the Windows User and Password and set AuthScheme to "NTLM".

      • Kerberos and Kerberos Delegation

        To authenticate with Kerberos, set AuthScheme to NEGOTIATE. To use Kerberos delegation, set AuthScheme to KERBEROSDELEGATION. If needed, provide the User, Password, and KerberosSPN. By default, the data provider attempts to communicate with the SPN at the specified Url.

      • SSL/TLS:

        By default, the data provider attempts to negotiate SSL/TLS by checking the server's certificate against the system's trusted certificate store. To specify another certificate, see the SSLServerCert property for the available formats.

      You can then access any cube as a relational table: When you connect the data provider retrieves SSAS metadata and dynamically updates the table schemas. Instead of retrieving metadata every connection, you can set the CacheLocation property to automatically cache to a simple file-based store.

      See the Getting Started section of the CData documentation, under Retrieving Analysis Services Data, to execute SQL-92 queries to the cubes.

      Built-in Connection String Designer

      For assistance in constructing the JDBC URL, use the connection string designer built into the SQL Analysis Services JDBC Driver. Either double-click the JAR file or execute the jar file from the command-line.

      java -jar cdata.jdbc.ssas.jar

      Fill in the connection properties and copy the connection string to the clipboard.

      When you configure the JDBC URL, you may also want to set the Max Rows connection property. This will limit the number of rows returned, which is especially helpful for improving performance when designing reports and visualizations.

      A typical JDBC URL is below.

      jdbc:ssas:User=myuseraccount;Password=mypassword;URL=http://localhost/OLAP/msmdpump.dll;
    • User Name: The username used to authenticate.
    • Password: The password used to authenticate.
    • SQL Statement: Enter an SQL query in the SQL Statement box or double-click a table. This article uses the query below to create a chart: SELECT Fiscal_Year, Sales_Amount FROM Adventure_Works
  5. Test the connection by clicking Fetch Metadata.

  6. Connect the Database Reader to a Data to Report node to supply the dataset to a range of data visualization controls. Click Execute and then click Edit Report at the top of the workflow to open the report designer perspective.
  7. You can now generate reports based on live data. To create a chart, drag the chart control from the palette to the report designer. In the resulting wizard, you can use the filtering and aggregation controls available in KNIME.

Troubleshooting

The following list shows how to resolve common errors:

  • Encountered duplicate row Id "Row1": To resolve this error, add the following to the knime.ini file located in your KNIME installation directory:-Dknime.database.fetchsize=0
