Rapidly Develop Sybase-Driven Apps with Active Query Builder

Write standard .NET to expose Sybase data through an SQL interface: Active Query Builder helps developers write SQL interfaces; the CData ODBC Driver for Sybase enables standards-based access to Sybase. This integration uses the Microsoft ADO.NET Provider for ODBC as a bridge between the ODBC Driver and the Active Query Builder objects to build a visual SQL composer.

Connect to Sybase as an ODBC Data Source

If you have not already, first specify connection properties in an ODBC DSN (data source name). This is the last step of the driver installation. You can use the Microsoft ODBC Data Source Administrator to create and configure ODBC DSNs.

To connect to Sybase, specify the following connection properties:

• Server: Set this to the name or network address of the Sybase database instance.
• Database: Set this to the name of the Sybase database running on the specified Server.

Optionally, you can also secure your connections with TLS/SSL by setting UseSSL to true.

Sybase supports several methods for authentication including Password and Kerberos.

Connect Using Password Authentication

Set the AuthScheme to Password and set the following connection properties to use Sybase authentication.

• User: Set this to the username of the authenticating Sybase user.
• Password: Set this to the username of the authenticating Sybase user.

Connect using LDAP Authentication

To connect with LDAP authentication, you will need to configure Sybase server-side to use the LDAP authentication mechanism.

After configuring Sybase for LDAP, you can connect using the same credentials as Password authentication.

Connect Using Kerberos Authentication

To leverage Kerberos authentication, begin by enabling it setting AuthScheme to Kerberos. See the Using Kerberos section in the Help documentation for more information on using Kerberos authentication.

You can find an example connection string below: Server=MyServer;Port=MyPort;User=SampleUser;Password=SamplePassword;Database=MyDB;Kerberos=true;KerberosKDC=MyKDC;KerberosRealm=MYREALM.COM;KerberosSPN=server-name

Use SQL to Interact with Sybase

Follow the steps below to create a WinForms visual query builder.

1. In a new Windows Forms project, drag the QueryBuilder from the Toolbox onto the form.
2. Add a reference to ActiveQueryBuilder.ODBCMetadataProvider.
3. Add an OdbcConnection and set the connection string to the DSN that you created in the first section. OdbcConnection connection = new OdbcConnection(); connection.ConnectionString = "DSN=Sybase"
4. Initialize ODBCMetadataProvider and GeneralSyntaxProvider instances and set the Connection property of the ODBCMetadataProvider object to the OdbcConnection. GenericSyntaxProvider syntaxProvider = new GenericSyntaxProvider(); ODBCMetadataProvider metadataProvider = new ODBCMetadataProvider(); metadataProvider.Connection = connection;
5. Set the corresponding MetadataProvider and SyntaxProvider properties of the QueryBuilder object. queryBuilder1.MetadataProvider = metadataProvider; queryBuilder1.SyntaxProvider = syntaxProvider;
6. Call the InitiatelizeDatabaseSchemaTree method of the QueryBuilder class to retrieve Sybase metadata and generate a tree view of Sybase tables. queryBuilder1.InitializeDatabaseSchemaTree();

7. After creating the QueryBuilder, connect it to a TextBox or, as we use, the ActiveQueryBuilder SQLTextEditor: Drag and drop an SQLTextEditor onto the designer.

8. Add the following code to the Validating event for the SQLTextEditor: private void sqlTextEditor1_Validating(object sender, CancelEventArgs e) { try { // Update the query builder with manually edited query text: queryBuilder1.SQL = sqlTextEditor1.Text; } catch (SQLParsingException ex) { e.Cancel = true; // Set caret to error position sqlTextEditor1.SelectionStart = ex.ErrorPos.pos; // Report error MessageBox.Show(ex.Message, "Parsing error"); } }
9. Add the following to the SQLUpdated event: private void queryBuilder1_SQLUpdated(object sender, EventArgs e) { sqlTextEditor1.Text = queryBuilder1.FormattedSQL; }

10. You can now build queries visually: Double-click a table in the Columns Pane Area and an entity/relationship diagram is displayed in the Query Building Area. Columns that you select in the diagram are added to the query.
