Build MVC Applications with Connectivity to BambooHR Data

In this article, we will guide you through the process of utilizing wizards within Visual Studio to seamlessly integrate the CData ADO.NET Provider for BambooHR into a basic MVC (Model, View, Controller) project.

Create the Entity Framework Model

Follow the steps below to save connection properties and map tables to entities in the data model.

1. Create a new MVC project in Visual Studio. In this example, the project name is MvcAPIApp.

2. If you are using Entity Framework 6, you will need to take the preliminary step of registering the BambooHR Entity Framework provider for your project. See the "LINQ and Entity Framework" chapter in the help documentation for a guide.

   Note that MVC 3 scaffolding and MVC 4 scaffolding do not support Entity Framework 6. You can use your scaffolding with Entity Framework 6 by upgrading to the latest version of MVC.

3. To add the .edmx file from the designer, right-click your Models folder and click Add New Item. Select ADO.NET Entity Data Model, name the model, and click Add. In this example, the name of the model is APIModel.
4. In the Entity Data Model wizard, select the option 'EF Designer from database'. The Entity Data Model wizard is displayed.
5. Click New Connection. Select CData BambooHR Data Source in the dialog that is displayed.

6. Specify the required connection string properties.

   Start by setting the Profile connection property to the location of the BambooHR Profile on disk (e.g. C:\profiles\bamboohr.apip). Next, set the ProfileSettings connection property to the connection string for BambooHR (see below).

   BambooHR API Profile Settings

   In order to authenticate to BambooHR, you'll need to provide your API Key. To generate an API key, log in and click your name in the upper right-hand corner of any page to get to the user context menu. If you have sufficient permissions, there will be an "API Keys" option in that menu to go to the page, where you can create a new API Key. Additionally, you will need to set the Domain, found in the domain name of your BambooHR account. For example if your BambooHR account is acmeinc.bamboohr.com, then the Domain should be 'acmeinc'. Set both the API Key and Domain in the ProfileSettings property to connect.

   A typical connection string is below:

   Profile=C:\profiles\BambooHR.apip;ProfileSettings='Domain=acmeinc;APIKey=your_api_key';

7. Name the connection and select whether to include sensitive information, such as connection credentials, in the connection string. For simplicity, this example saves sensitive information in Web.config. The connection settings are saved as APIEntities.

8. Select the views you need. In this example, Employees is imported. Also, the option to pluralize object names is deselected in this example. Click Finish to create the .edmx file.
9. Build your project to complete this step.

Scaffold the Controller and Views

Once you've established the model and completed the project build, you can employ ASP.NET Scaffolding wizards to generate both the controller and the views.

1. In Solution Explorer, right-click the controllers folder and click Add -> Controller. Select MVC 5 Controller with views, using Entity Framework.
2. In the Add Controller dialog that is then displayed, select the following options:
   • Model class: Select a table you imported; for example, Employees.
   • Data context class: Select your context class.
3. Leave the default values for the other fields.
